Instruction Manual, HD-1500 / HD-3000 Series SPECIFICATIONS 3
May 26, 2009
MAINTENANCE
There are no user serviceable parts or internal adjustments other than the jumper
selections described above. For repair and service, please call the factory.
SPECIFICATIONS
General:
Power: .............................................................................................. 5-24V / 1A
Typical Range (2.97G/1.485G/270M) ............................................... >10KM/20KM/35KM
Standards Supported: ....................................................................... SMPTE 259M-C
SMPTE
292M
SMPTE 425M
2
SMPTE 297M
DVB/ASI
Transmitter (-FTX):
Input Type: ....................................................................................... 1 BNC
Input Impedance: .............................................................................. 75 Ohms
Loop Output Type: ............................................................................. 1 BNC
Loop Output Impedance .................................................................... 75 Ohms
Input and Loop Output Return Loss: ................................................. >15dB up to 1.5GHz
>10dB up to 3 GHz
2
Fiber Output Type: ............................................................................ ST or SC
Wavelength: ...................................................................................... 1310nm Single mode
Optical Power: ................................................................................... –12 dBm to –7.5 dBm
Laser Strength: .................................................................................. Laser Class 1
Receiver (-FRX):
Fiber Input Type: .............................................................................. ST or SC
Wavelength: ...................................................................................... 1100 to 1600nm
Optical Sensitivity: ............................................................................ -20 dBm
Output Type: ..................................................................................... 2 X BNC
Output Impedance: ………………………………………………………75 ohms
Output Return loss: ........................................................................... >15 dB up to 1485MHz
>10dB up to 3 GHz
2
Output Jitter: ...................................................................................... <0.2UI
Specifications are subject to change without notice.
2 Only HD-3000
