background image

TECHNICAL SPECIFICATIONS

Impedance (ohm)
SPL 1w/1m(dB)
Qes
Qts
Fs (Hz)
Vas (L)
Cms (mm/N)
Mms (g)
Sd (M²)
BL (T·M)
Re
Xmax (mm)

4*
84.5
0.54
0.49
32.0
14.6
0.095
296
0.033
18.5
3.3
15

8*
84.5
0.55
0.50
33.0
13.9
0.090
267
0.033
24.8
6.2
16

4*
86
0.55
0.49
31.0
30.3
0.087
311
0.0497
19.0
3.3
15

8*
86
0.54
0.49
32.0
28.9
0.083
298
0.0497
26.2
6.2
16

M6 10D4

M6 12D2

M6 12D4

M6 10D2

A

B

DIMENSION

A

(bolt circle diameter)

B

(outside diameter)

C

(height)

D

(Thru Hole diameter

)

Displacement

M6 10

246mm
270mm
138mm
228mm
2.63 L

M6 12

294mm
320mm
150mm
276mm
3.33L

METRIC DIMENSIONS

IMPERIAL DIMENSIONS

DIMENSION

A

(bolt circle diameter)

B

(outside diameter)

C

(height)

D

(Thru Hole diameter

)

Displacement

M6 10

9.685"
10.629"
5.433"
8.976"
0.093 ft

3

M6 12

11.575"
12.598"
5.905"
10.866"
0.117ft

3

DIMENSIONS AND VOLUMES

THIELE/SMALL PARAMETERS

The information below is provided to enable custom enclosure design and is
intended for professional use only. Please consult your Authorized Diamond Retailer
for an enclosure which best suits your requirements.

RECOMMENDED ENCLOSURES

Diamond's M6 Series subwoofers are primarily designed for use with small sealed
enclosures. Good results have also been achieved in vented and bandpass
enclosures. Although “free-air” (infinite-baffle) applications are NOT recommended,
they may be used successfully in low-power systems (e.g., 75W or less per sub).
HIGH PASS ("SUBSONIC") FILTERS MUST BE USED WITH NON-SEALED APPLICATIONS
TO PREVENT OVER-EXCURSION AT INFRASONIC FREQUENCIES.
The enclosure volumes shown below are NET INTERNAL VOLUMES. Driver, vent and
brace displacement must be taken into account when designing your enclosure.

Titanium Magnesium Alloy Cone - H

igh rigidity, smooth linear response

Die-cast Alloy Chassis -

High strength maintains critical parts alignment

NBR Rubber Surround -

Durable at environmental extremes. Large roll allows long stroke

Machined Backplate/Pole -

Precision engineered to exacting tolerance

Aluminum VC Former -

400% stronger than Kapton®, excellent heat transfer

3" Dia. Pure Copper Coil -

4-layer design. High thermal/current capacity for high power handling.

Mirror Image Dual Nomex® Spiders with woven lead wires -

Enormous controlled

excursion, ultimate durability, no lead slap.

3-Year Warranty -

If purchased from and installed by an Authorized Diamond Retailer.

FEATURES

INSTALLATION

The installations and enclosures shown in this manual are offered as a suggestion
only. Since enclosure design is as important to sound quality as the speaker itself, it
is recommended that your Authorized Diamond Retailer assist you in designing and
building an enclosure to suit your vehicle. For more information on selecting the
best subwoofer enclosure, consult the "FAQ" page of our web site,
www.diamondaudio.com

C

D

*parameters shown are with voice coils wired in series

M6 10D4

M6 12D2

M6 12D4

M6 10D2

SEALED ENCLOSURE

VENTED ENCLOSURE

Vb (Net vol ft

3

)

F3 (Hz)
Pe (Watts)
Qtc (@ max pwr)

Vb (Net vol ft

3

)

F3 (Hz)
Fb (Tuning freq.)
Pe (Watts)
Ports
Port I.D.
Port Length

.75~.3
42~37
800~600
0.9~1.2

0.75
33
32
600
2
2"
20"

.75~.3
42~37
800~600
0.9~1.2

0.75
33
32
600
2
2"
20"

1.75~.6
44~35
800~600
0.9~1.2

1.5
35
31
600
1
4"
18"

1.75~.6
44~35
800~600
0.9~1.2

1.5
35
31
600
1
4"
18"
