Page 4
4
The XHD7714 allows playback of your favorite MP3 and WMA files recorded on CD-R and
CD-RW discs. Its powerful on-board DSP processor decodes the compressed audio while
maintaining near-CD sound quality. An internal SRAM buffer provides ESP (Electronic
Skip Protection) to virtually eliminate skipping and allows alphanumeric or direct track
search - even while a song is currently playing!
XHD7714
OPERATION
Control Locations - Receiver
Open
Talk
Mute/End Call
Tune/Track Down
Power ( )/Select
Tune/Track Up
Preset 1/Repeat
Preset 3/Intro
Preset 2/Random
Preset 4/Play/Pause
Auxiliary Input
1
2
3
4
5
6
7
8
9
10
11
USB Port
Preset 6/Folder Up
Preset 5/Folder Down
Display
Volume
Mode/EQ
Bluetooth Microphone
Band/ESC
Audio/Menu
Scan/HD Seek
Tag
12
13
14
15
16
17
18
19
20
22
20
19
18
17
16
15 14
13
2
3
5
6
7
8
9
12
11
10
1
4
21
21
22
