25 104060
OWNER’S MANUAL
PARTS LIST
VMH26TNA
This list contains replaceable parts used in
your fireplace. When ordering parts, follow
the instructions listed under Replacement
Parts on page 26 of this manual.
KEY NO. PART NO. DESCRIPTION QTY.
1 102633-02CK Outer Casing Top 1
2 102624-02 Outer Casing 1
3 099230-02 Shoulder Screw 12
4 098304-01 Screw, #10 x 3/8" 14
5 103447-02 Burner 1
6 103209-03 Louvered Door 1
7 102635-02CK Left and Right Side Front 2
8 101629-02 Bushing 1
9 103209-01 Brass Top Louver 1
10 101712-04 Firebox Hood 1
11 102638-01 Firebox Top 1
12 103042-01 ODS/Pilot Assembly 1
12-1 098514-01 Thermocouple 1
12-2 098594-01 Ignitor Electrode 1
13 102460-01CJ Firebox Wrapper 1
14 099211-01 Control Bracket Screw 2
15 103963-01 Inlet Tube 1
16 102834-01 Burner Tube 1
17 100587-01 Brass Screw, #6 x 3/8 4
18 098303-02 Regulator Screw 2
19 104335-01CK Outer Shell Base 1
20 102649-01CJ Branch Support 1
21 099415-10 Gas Regulator 1
22 102875-01 Regulator Bracket 1
23 101381-01 Valve Cover and Piezo 1
24 099387-11 Pilot Tube 1
25 098271-06 Ignitor Cable 1
26 103845-12 Injector 1
27 102458-01CK Front, Top Middle 1
28 098249-01 Nut, M5 6
29 098522-14 Gas Valve 1
30 102639-01 Baffle 1
31 101628-01 Flexible Connector 1
32 102869-01 Control Bracket 1
33 102731-01 Control Shield 1
34 103295-01CJ Screen Assembly 1
35 103058-01 Log Set Assembly 1
35-1 104058-01 Branch Service Kit 1
35-2 104058-02 Back Log Service Kit 1
36 104313-01 Right Hinge 1
37 104313-02 Left Hinge 1
38 M10908-2 Hinge Screws 4
39 102645-02 Burner Support, Right 1
40 102645-03 Burner Support, Left 1
41 097809-03 3/8" NPT x 3/8" Flare Brass Fitting 1
42 101629-01 Bushing 1
43 M11084-26 Hex Head Screw, #10 x 3/8" 28
PARTS AVAILABLE — NOT SHOWN
104319-02 Information Video 1
101054-01 Lighting Instructions Plate 1
100563-01 Warning Plate 1
103470-01 Hardware Package 1
