Technical Data
General specifications
Dimensions:
Width: 680 cm (22.30 ft.)
Depth: 167 cm (5.47 ft.)
Height: 198 cm (6.49 ft.)
Weight:
approx. 4500 kg (9900 lb.)
Safety standards:
Complies with currently valid
guidelines
Printing specifications
Printing system:
Roll to Roll transport system with
Quadro® Array Technology
Resolution:
600 dpi
Colours
Standard: CMYK
Optional: Light Cyan and Light
Magenta, White, clear varnish,
selected spot colours (on request)
Inks:
Rho Roll Ink - UV-curable pigment
inks for indoor and outdoor
applications. The Rho Roll Ink,
pigments classified at Blue Wool
scale 8. The inks are VOC free.
Ink supply:
Integrated ink tanks with 10 litre
capacity per colour, refillable
during the printing process.
The refill inks are in 5 litre,
non-returnable containers, easily
disposed in collapsed condition,
thus avoiding pollution to the
machine and the environment.
Software/RIP:
Durst Rho Touch Screen Linux
Software for very fast processing
with minimum storage capacity on
the hard disk. External Caldera RIP
Server with GrandRip+ Software
Productivity:
Up to 130m 2 /hour
(1400 sq.ft./hour) - continuous
printing
Media specifications
Media types:
Wide range of uncoated and
coated roll media types like
bannermedia, Vinyl, tarpaulin,
truck-banner, polyester, textiles,
canvas, paper, self-adhesive PVC,
PVC/PA-transparent media types,
Mesh etc.
Maximum printing width:
320 cm (10.5 ft.)
Max. printing length:
Only restricted by media length
Maximum thickness:
2 mm (depending on media)
Max. roll diameter:
450 mm (17.7 in.) outside diameter
Max. roll weight:
approx. 300 kg (661 lb.)
Ambient conditions:
Space requirement:
approx. 9 x 9 m (30 x 30 ft.)
Max. sea level of installation:
2400 m above sea level (8000 ft.)
Max. ambient temperature:
+15 °C to +30 °C (+59°F to 86°F)
Max. humidity:
25 - 80 %, not condensing
