Cavity Car-
tridge
Fuse Mini-
Fuse Description
8 — 15 Amp
Blue Diagnostic Link Connec-
tor (DLC)/Wireless Con-
trol Module (WCM)/
Wireless Ignition Node
(WIN)
9 — 20 Amp
Yellow Power Outlet
10 — — —
11 * — — —
12 * — — —
13 * — — —
14 — 10 Amp
Red AC Heater Control/
Cluster/Security Mod-
ule - if equipped
15 — — —
16 — — —
Cavity Car-
tridge
Fuse Mini-
Fuse Description
17 — 20 Amp
Yellow Cluster
18 — 20 Amp
Yellow Selectable Power Outlet
19 — 10 Amp
Red Stop Lights
20 — — —
21 — — —
22 — — —
23 — — —
24 — — —
25 — — —
26 — — —
27 — 10 Amp
Red Occupant Restraint Con-
troller (ORC)
MAINTAINING YOUR VEHICLE 385
7
