PARTS LIST
BURNER ASSEMBLY FOR MODELS
(V)K42N, (V)K42NH, (V)K42P, (V)K42PH
This list contains replaceable parts used in your fireplace. When
ordering parts, follow the instructions listed under Replacement
Parts on page 31 of this manual.
PARTS LIST
(V)K42N, (V)K42NH, (V)K42P, (V)K42PH
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 111920-01 Pan Assembly Burner 1
2 111311-02 Grate Base 1
3 111313-02 Burner Base Bottom 1
4 26808 Valve Bracket 1
5 11107 Screw, #10-32 x 1/4 PPH Zinc 4
6 111310-02 Firebox Bottom 1
7 11102 Screw, #8-32 x 3/8 PPH Zinc 2
8 111912-01 Tubing Assembly 1
9 111288-02 Flex Gas Line 1
10 108084-02 Pilot Assembly (Natural Gas) 1
108084-03 Pilot Assembly (Propane/LP Gas) 1
11 14389 Hi-Lo Natural Gas Valve 1
14390 Hi-Lo Propane/LP Gas Valve 1
12 11165 Screw, #10 x 5/8 HWH Zinc 22
13 111913-02 Burner Base Gasket 1
14 14500 Brass Fitting 1
15 111315-01 Pilot Bracket 1
16 104506-27 Burner Orifice #31 (Natural Gas) 1
104506-26 Burner Orifice #50 (Propane/LP Gas) 1
17 26827 Switch Bracket 1
