Dual XR4115 - Manual (Page 14)

14
XR4115 OPERATION
Specifications
Tuning range: 87.5MHz-107.9MHz
Usable sensitivity: 10dBf
50dB quieting sensitivity: 25dBu
Stereo separation @ 1kHz: >30dB
Frequency response: 30Hz-18kHz
Tuning range: 530kHz-1710kHz
Usable sensitivity: <42dBu
Frequency response: 80Hz-2kHz
Speaker output impedance: 4~8 ohms
Line output voltage: 1.5 Volts RMS
Dimensions: 7" x 2" x 5" (178 x 50 x 130 mm)
Design and specifications subject to change without notice.
FM Tuner
AM Tuner
General
CEA-2006 Power Standard Specifications
(reference: 14.4VDC +/- 0.2V, 20Hz~20kHz)
Power Output: 18 Watts RMS x 4 channels at 4 ohms and < 1% THD+N
Signal to noise ratio:
70 dBA (reference: 1 watt into 4 ohms)
