8

© 1999 Directed Electronics, Inc

SPECIFICATIONS 150/250/400

RMS continuous power per channel, both chan-
nels driven into 4 ohms from 20 to 20,000 Hz,
with less than 0.08% Total Harmonic Distortion
@ 14.4 VDC
RMS continuous power per channel, both chan-
nels driven into 2 ohms from 20 to 20,000 Hz,
with less than 0.1% Total Harmonic Distortion @
14.4 VDC
RMS continuous power bridged into a 4 ohm
load from 20 to 20,000 Hz, with less than 0.1%
Total Harmonic Distortion @ 14.4 VDC
Dynamic power rating (IHF-202 Standard)
bridged into 4 ohms

50 75

125

watts

watts

watts

75 125

200

watts

watts

watts

150 250

400

watts

watts

watts

200

325

550

watts

watts

watts

model 150 250 400

Signal-to-Noise Ratio Greater than 95 dB

Frequency Response 20-20,000 Hz ± 0.5 dB

Damping Factor @ 4 ohm Greater than 200

Crossover

Switchable high or low pass

12 dB/octave, continuously

variable from 50 to 500 Hz

Bass Equalization +8 dB, centered at 40Hz

Input Impedance 20K ohms

Input Sensitivity Variable from 150 mV to 8 volt

Output Impedance 2 to 8 ohms, stereo

4 to 8 ohms, bridged

Supply Voltage 10 to 16 VDC

Fusing and Power 20A 25A 50A
Cable Requirements (AWG) #12 #10

#8

(Per amp, trunk mounted)
