21 106573
OWNER’S MANUAL
OPERATING
FIREPLACE
WARNING: If you do not fol-
low these instructions exactly, a
fire or explosion may result caus-
ing property damage, personal
injury or loss of life.
A. This appliance is equipped with an
ignition device which automatically
lights the main burner. These mod-
els do not have a pilot assembly.
B. BEFORE LIGHTING smell all
around the appliance area for gas. Be
sure to smell next to the floor because
some gas is heavier than air and will
settle on the floor.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electric switch; do
not use any phone in your building.
• Immediately call your gas supplier
from a neighbor's phone. Follow
the gas supplier's instructions.
C. Use only your hand to push in or turn
the gas control knob. Never use tools.
If the knob will not push in or turn
by hand, don't try to repair it, call a
qualified service technician. Force or
attempted repair may result in a fire
or explosion.
D. Do not use this appliance if any part
has been under water. Immediately
call a qualified service technician to
inspect the appliance and to replace
any part of the control system and
any gas control which has been un-
der water.
FOR YOUR SAFETY
READ BEFORE
LIGHTING
LIGHTING
INSTRUCTIONS
1. STOP! Read the safety information
in column one.
2. Open lower louver panel.
3. Turn wall switch to “OFF”.
4. Turn off all electric power to the
fireplace.
5. Turn the equipment shuttof valve
clockwise
to the OFF position
(see Figure 52). Do not force.
6. Wait five (5) minutes to clear out any
gas. Then smell for gas, including
near the floor. If you smell gas,
STOP! Follow “B” in the safety in-
formation in column one. If you don't
smell gas, go to the next step.
7. Turn equipment shutoff valve counter-
clockwise
to the ON position.
8. Turn on all electrical power to the
appliance.
9. Turn the wall switch to the ON
position.
10. Visually locate the electrode assem-
bly. The electrode is located by the
main burner. The ignitor should be-
gin to spark and the main burner
should ignite.
• If lighting the appliance for the
first time each season, it may take
several attempts before the supply
gas can reach the main burner.
• If the appliance will not stay lit af-
ter several attempts, follow the in-
structions To Turn Off Gas To Ap-
pliance, column 3, and call your
service technician or gas supplier.
11. Close lower louver panel.
TO TURN OFF GAS
TO APPLIANCE
1. Turn off the wall switch.
2. Turn off all electric power to the ap-
pliance if service is to be performed.
3. Open control access panel.
4. Turn equipment shutoff valve clock-
wise
Clockwise
to “OFF”. Do not force.
5. Close control access panel.
Figure 52 - Turning the Equipment Shutoff
Valve to the OFF position
Equipment Shutoff Valve
Control Valve
Figure 53 - Electrode
OPTIONAL REMOTE
OPERATION
Note: The WRC receiver and hand-held
remote control kit must be purchased
separately (see Accessories, page 26). Fol-
low installation instructions on page 17.
1.
Turn equipment shutoff valve to ON
position. You can now turn the
burner on and off with the hand-held
remote control unit.
IMPORTANT: Be sure to press the
ON/OFF buttons on the hand-held
remote control unit for up to 3 sec-
onds to assure proper operation.
2. Press the ON/OFF button to turn the
burner on and off.
