ILLUSTRATIONS
The photograph above, with lower basket removed, shows you the main parts
described in this instruction manual.
1
2
3
Soundproofing apron
For optimum soundproofing, make sure the
apron delivered with the machine is correctly
installed.Having adjusted the feet for height :
①
- Tilt the dish-washer backwards slightly so as
to clip the apron onto the bottom of the
plinth. Make sure it is correctly clipped at
both ends and the centre.
②
- Adjust the height of the apron; snip the
end with a pair of scissors and cut one or
more strips off it by hand.
The apron should touch the floor.
15
①
②
4
1. Work top
2. Upper basket
3. Washing detergent distributor
4. Self-cleaning microfilter
5. Rating plate
6. Lower spray arm
7. Main filter
8. Waste trap
9. Rinse aid distributor
8
9
2
3
4
5
6
7
1
