Cleaning
The cooker hood should be cleaned regularly internally and externally.
For cleaning use a cloth moistened with denatured alcohol or neutral
liquid detergents. Avoid abrasive detergents.
Warning:
Failure to carry out the basic standards of the cleaning of the cooker
hood and replacement of the filters may cause fire risks.
Therefore we recommend observing these instructions.
Maintenance
Prior to any maintenance operation ensure that the cooker hood is
disconnected from the power supply.
Grease filter
This must be cleaned once a month non aggressive detergents,
either by hand or in the dish-washer, which must be set to
a low temperature and a short cycle.
When washed in a dish-washer, the grease filter may
discolour slightly, but this does not affect its filtering capacity.
To remove the grease filter, pull the spring release
handle. Fig1 (3)
Charcoal filter (filter version only)
It absorbs unpleasant odours caused by cooking.
The carbon filter should be replaced every six months.(and
1. Slide out the vapour collector.
2. Remove the grease filter.
3. If the carbon filter is already mounted and requires
replacement, depress the unblocking key (S - Fig. 10)
and remove the filter downward.
4. Remount the grease filter.
I f t h e c a r b o n f i l t e r i s n o t m o u n t e d :
1. Slide out the vapour collector.
2. Remove the grease filter.
3. Insert the carbon filter in the upper hooks T and fix it
using the lower hooks S (Fig. 10).
4. Remount the grease filter.
Replacing lamps - Fig. 4
Remove grease filter and push light fitting downwards to access
bulb.
W a r n i n g !
Prior to touching the light bulbs ensure they are cooled down.
Model with halogen light bulbs.
Replace the light bulb with a new PHILIPS STANDARD
LINE code 425409 12V 20W 30° Ø35 12V GU4.
Carry out the replacement and the mounting of the new
light bulb following the procedure in reverse.
Replacement lamps are not covered by warranty.
If the lights do not work, make sure that the lamps are
fitted properly into their housings before you call for
technical assistance.
Caution
This appliance is designed to be operated by adults. Children should
not be allowed to tamper with the controls or play with the appliance.
Do not use the cooker hood where the grill is not correctly fixed! The
suctioned air must not be conveyed in the same channel used for
fumes discharged by appliances powered by other than electricity.
The environment must always be adequately aerated when the
cooker hood and other appliances powered by other than electricity
are used at the same time. Flambé cooking with a cooker hood is
prohibited. The use of a free flame is damaging to the filters and may
cause fire accidents, therefore free flame cooking must be avoided.
Frying of foods must be kept under close control in order to avoid
overheated oil catching fire. Carry out fumes discharging in
accordance with the regulations in force by local laws for safety and
technical restrictions.
INSTRUCTION ON MOUNTING AND USE
Consult the designs in the front pages referenced in the text by alphabet letters. Closely follow the instructions set out in this manual. All responsibility,
for any eventual inconveniences, damages or fires caused by not complying with the instructions in this manual, is declined.
GB
If the hood fails to operate correctly, briefly disconnect it from the
mains power supply for almost 5 sec. by pulling out the plug. Then
plug it in again and try once more before contacting the Technical
Assistance Service.
Warning!
Always press the fan off button A before disconnecting the hood from
the mains supply.
Operation –
Model with button panel
A. on/off light switch
B. on/off switch and minimum power selection
C. medium power selection switch
C+D. maximum power selection switch
Use the high suction speed in cases of concentrated kitchen
vapours. It is recommended that the cooker hood suction is switched
on for 5 minutes prior to cooking and to leave in operation during
cooking and for another 15 minutes approximately after terminating
cooking.
A B C
D
