Technical characteristic tables, Wiring diagram – Kleenmaid GCT6020 User Manual
Page 15
11
TECHNICAL CHARACTERISTIC TABLES
BURNERS
GAS
NORMAL
PRESSURE
INJECTOR
DIAMETER
TAPE BY
PASS
DIAMETER*
NOMINAL
HEAT INPUT
(MJ/h)
N° DESCRIPTION
KPa
1/100 mm
1/100 mm
1
RAPID
Universal LPG
2.75
85
42
9.6
Natural
1.00
152
3/8
11.2
2
SEMI-RAPID
Universal LPG
2.75
65
31
5.6
Natural
1.00
110
3/8
6.0
3
AUXILIARY
Universal LPG
2.75
52
27
3.4
Natural
1.00
80
3/8
3.2
4
TRIPLE
CROWN
Universal LPG
2.75
90
60
10.4
Natural
1.00
150
1 1/2
10.8
5
DOUBLE
CROWN
Universal LPG
2.75
85
60
9.6
Natural
1.00
145
7/8
10.3
MODEL: GCT6020
MODEL: GCT9020
IGNITION
GENERATOR
TRIPOLAR
TERMINAL
MICRO-UNIT
IGNITION
GENERATOR
TRIPOLAR
TERMINAL
MICRO-UNIT
WIRING DIAGRAM
*TAPE BY PASS DIAMETER: ULPG - 1/100 mm
NG - Turns from fully in.
