OWNER’S MANUAL
For more information, visit www.desatech.com
PARTS LIST
REMOTE READY MODEL
VI33PR
This list contains replaceable parts used in your fireplace. When ordering parts, follow the
instructions listed under Replacement Parts on page 20 of this manual.
KEY
NO.
PART NUMBER DESCRIPTION QTY.
1 102785-03 Log, Golden Oak 1
2 103778-01 ODS Pilot (Propane/LP) 1
3 098249-01 ODS Nut 2
4 099387-07 Pilot Tube 1
5 104229-02 Burner Outlet Tube 1
6 102843-01 Burner Clip 1
7 099056-19 Burner Orifice Injector 1
8 102772-01 Burner 2
9 M11084-38 Screw, #8 x .38 2
10 104236-01CK Painted Base Assy 1
11 M12461-26 Screw, #10 x .32 4
12 104238-01CK Firebox Bottom 1
13 103284-03 Wiring Harness 1
14 098265-02 Elbow, Male 1
15 103782-01 Valve Bracket 1
16 103781-02 Gas Control Valve 1
17 098271-03 Ignitor Cable 1
18 102445-01 Piezo Ignitor 1
19 098304-01 Screw 7
20 099998-01 Switch 1
21 104241-01 Remote Switch Bracket 1
22 103587-01CK Switch Plate 1
23 097809-02 Male Connector 1
24 101628-03 Flexible Connector (Hose) 1
25 M50104-02 Bushing 1
26 M11084-26 Screw, #10 x .38 4
PARTS AVAILABLE — NOT SHOWN
104354-01 Information Video 1
103877-01 Lighting Instruction Plate 1
100563-01 Warning Plate 1
