27
Reserved I/O
User this item to set reserved I/O (4L/8K/12K/16K/20K) range for this root bridge.
Azalia HD Audio
The optional settings are: [Disabled]; [Enabled];[Auto].
Azalia Internal HDMI Codec
Use this item to enable or disable internal HDMI codec for Azalia.
Onboard LAN1 Controller
Use this item to enable or disable onboard LAN controller.
Wake on LAN1 from S5
Use this item to enable or disable integrated LAN to wake the system.
Onboard LAN2 Device
Use this item to control the PCI Express root port.
DeepSx Power Policies
Use this item to configure the Deep Sx Mode configuration.
High Precision Event Timer Configuration
High Precision Timer
The optional settings are: [Enabled]; [Disabled].
Restore AC Power Loss
Use this item to select AC power state when power is re-applied after a power
failure. The optional settings are: [Power Off]; [Power On]; [Last State].
► System Agent (SA) Configuration
Press [Enter] to make settings for the following sub-items:
Enable NB Card
The optional settings are: [Enabled]; [Disabled].
► Graphics Configuration
Press [Enter] to make further settings for Graphics Configuration.
Graphics Configuration
Primary Display
The optional settings are: [Auto]; [IGFX]; [PEG]; [PCI].
Internal Graphics
The optional settings are: [Auto]; [Disabled]; [Enabled].
CTT Size
The optional settings are: [1MB]; [2MB].
Aperture Size
The optional settings are: [128MB]; [256MB]; [512MB].
DVMT Pre-Allocated
Use this item to select DVMT 5.0 pre-allocated (fixed) graphics memory size used
by the internal graphics device.
DVMT Total Gfx Mem
Use this item to select DVMT 5.0 total graphics memory size used by the internal
graphics device.
GFx Low Power Mode
The optional settings are: [Disabled]; [Enabled].This option is applicable for SFF
only.
