5
1 1 Door latch - When the door is closed it will
automatically shut off. If the door is opened
while the oven is operating, the magnetron will
automatically shut off.
2 2 Door seal - The door seal maintains the
microwave within the oven cavity and prevents
microwave leakage.
3 3 Oven cavity
4 4 Spatter shield - Protects the microwave outlet
from splashes of cooking foods.
5 5 Safety interlock system - Prevents the oven
from operating while the door is opened.
6 6 Control Panel
7 7 Glass cooking tray - Made of special heat
resistant glass. The tray must always be in
proper position before operating.
Do not cook food directly on the tray.
8 8 Roller guide - Supports the glass cooking tray.
9 9 Door screen - Allows viewing of food.
The screen is designed so that light can pass
through, but not the microwaves.
FEATURES DIAGRAM
1 2 4 5
6
7 8 3 9
