PARTS LIST
This list contains replaceable parts used in your fireplace. When
ordering parts, follow the instructions listed under Replacement
Parts on page 22 of this manual.
FIREPLACE
VSGF28NTC
KEY
NO.
PART NUMBER DESCRIPTION QTY.
1 101357-01 Top Outer Casing 1
2 ** Outer Casing 1
3 102758-02CK Right Front Side 1
4 102759-02CK Left Front Side 1
5 098304-01 Phillips Pan Head Screw, #10 17
6 101351-01CK Top Front 1
7 102455-02 Top Louver Assembly 2
8 101353-01CK Middle Front Rail 1
9 101712-02 Firebox Hood 1
10 101348-01 Firebox Support 2
11 099230-01 Shoulder Screw 4
12 101872-03 Firebox Top 1
13 101346-01 Outer Base 1
14 ** Firebox Wrapper 1
15 101614-02 Limit Switch (thermal disk) Assy. 1
16 M11084-26 Hex Screw, #10 57
17 098304-03 Phillips Pan Head Screw, #8 4
18 101727-03 Screen Assembly 1
19 101398-03 Wire Harness 1
20 103650-01 Control Knob 1
21 103581-02 Blower Assembly 1
22 099123-01 Wire Clip 4
23 105649-01 Blower Speed Control 1
24 M11084-38 Hex Screw, 8-18 x .38" 4
25 101629-01 Plastic Bushing 2
26 098544-01 Clamp 1
PARTS AVAILABLE — NOT SHOWN
099038-01 Strain Relief Bushing 1
100639-01 Caution Decal 1
103590-01 Decal Strip 1
104313-01 Hinge, Pin 1
104313-02 Hinge, Pin 1
M10908-2 Screw, Slotted Hex Head Tapping 4
** Not a field replaceable part.
PARTS LIST
Fireplace
Model VSGF28NTC
