Desa GENERATOR - Manual (Page 4)

Resistance in Ohms
Rated Stator Main Stator Auxiliary Rotor Primary Rotor Secondary Capacitor, Diodes,
Watts Winding * Winding
∆
Winding † Winding † MFD 450 Volt (2) 800 Volt
10,000 0.4 0.9 0.37 0.5 80 70Amp
P.O. Box 90004
Bowling Green, KY 42102-9004
Technical Service Department 1-800-858-8501
www.desatech.com
103166-01
Rev. D
07/03
250V 30A
Receptacle
250V 50A
Receptacle
125V, 15A
Receptacle
GFCI 125V, 15A
Receptacle
125V, 30A
Receptacle
Circuit
Breaker
20A
Circuit
Breaker
20A
Green
Green
Black
Black
White Black
Red
Black Black
Black Black
Black
White White
White
Green
Black
Black
Black
Red
Red
Red
Red
Yellow
Yellow
White
White
Auto-Idle
Control Board
Yellow
White White
White
Circuit
Breaker
30A
Circuit
Breaker
30A
Circuit
Breaker
45A
Circuit
Breaker
45A
Green
T2
Green
Black
Red
White
Main
Windings
T1 T3 T4
Wh
T1 T2 T3 T4
Rotor
Diode Diode
Stator
Capacitor
White White
Run
Light
Hour Meter Gree
n
L1 S2
Solenoid
S1 T1-3 L2
To
Auto-Idle
Solenoid
Stator
110/120V
T1 T2 T3 T4
L2 L1
110/120V
220/240V
* Connect T2 and T3. Measure resistance between T1 and T4.
∆ Disconnect capacitor leads in order to read auxillary winding resistance.
† Remove diodes to check resistance.
