Connect the DC Power Cable to the V8000HDMI monitor.
V8PBK-A
(V8000HDMI Pro Battery Kit) QUICKSTART GUIDE
Insert the DC Cable in the connection slot.
Connect both Pro Battery DC cables. Attach the Pro Battery Plate and the monitor with M4X.07 20mm Bolts.
** Only for old V8000HDMI model with strap hooks**
Connect both Pro Battery DC cables. Attach the Pro Battery Plate, the Spacers and the monitor with
M4X.07 20mm Bolts.
