BIOS Setup
20 MB839 Series User’s Manual
Serial Port Console Redirection
Aptio Setup Utility
Main Advanced Chipset Boot Security Save & Exit
COM0
→ ←
Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
Console Redirection
►Console Redirection Setting
Serial Port for Out-of Band Management /
Windows Emergency Management Services (EMS)
[Enabled]
Console Redirection
►Console Redirection Settings [Disabled]
Console Redirection Setting
Main Advanced Chipset Boot Security Save & Exit
COM0
→ ←
Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
Console Redirection Settings
Terminal Type
Bits per second
Data Bits
Parity
Stop Bits
[VT100]
[115200]
[8]
[None]
[1]
Flow Control [None]
VT-UTF8 Combo Key Support
Recorder Mode
Resolution 100x31
Legacy OS Redirection Resolution
Putty KeyPad
Redirection After BIOS POST
[Enabled]
[Disabled]
[Disabled]
[80x24]
[VT100]
[Always Enable]
CPU Configuration
This section shows the CPU configuration parameters.
Aptio Setup Utility
Main Advanced Chipset Boot Security Save & Exit
Socket 0 CPU Information
→ ←
Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
Intel(R) Celeron(R) CPU J1900 @ 1.99 GHz
Processor Speed 1990 MHz
Processor Cores 4
Intel HT Technology Not Supported
Intel VT-X Technology Supported
L1 Data Cache 24 kB x 4
L2 Data Cache 32 kB x 4
L2 Cache 1024 kB x2
