BIOS SETUP
32 MI953 User’s Manual
Intel IGD SWSCI OpRegion
Aptio Setup Utility
Main
Advanced
Chipset Boot Security Save & Exit
Intel IGD SWSCI OpRegion Configuration
→ ←
Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit
DVMT/FIXED Memory 256MB
IGD – Boot Type VBIOS Default
Active LFP No LVDS
Panel Color Depth 18 Bit
LFP LCD Panel Type 1024 x 768 LVDS
Panel Scaling Auto
DVMT/FIXED Memory
Select DVMT/FIXED Mode Memory size used by Internal Graphics Device.
Options are 128MB, 256MB and Maximum.
IGD – Boot Type
Select the Video Device which will be activated during POST. This has no effect
if external graphics present. Options are VBIOS Default, CRT, LFP, CRT+LFP,
EFP and CRT+EFP.
Active LFP
Select the Active LFP Configuration.
No LVDS: VBIOS does not enable LVDS.
Int-LVDS: VBIOS enables LVDS driver by Integrated encoder.
SDVO LVDS : VBIOS enables LVDS driver by SDVO encoder.
eDP: LVDS Driven by Int-DisplayPort encoder.
Panel Scaling
Select the LCD panel scaling option used by the Internal Graphics Device.
Options are Auto, Force Scaling, Off and Maintain Aspect Ratio.
