Legatia Pro User’s Manual ©Hybrid Audio Technologies Page 11 of 43
Thiele/Small Parameters
Overall Diameter Φ 58 mm
Mounting Depth 30 mm
Mounting Methodology Surface-mount tweeter with standard-pitch M47.5 X
8mm thick knurled thread aluminum adapter to
secure the tweeter body from the rear
Construction Solid machined aluminum with integrated
polypropylene rear cap and push terminals
Distortion <5% max at rated power input, no crossover
Magnet Diameter and Construction Φ 24.5 × 3 H NdFeB
Recommended Minimum Crossover Frequency 2,000 Hz at 24 dB/octave highpass
P
nom
Rated Power Input (No Crossover) 20 watts (AES Standard)
P
max
Rated Power Input (No Crossover) 40 watts (AES Standard)
P
max
(With Recommended Minimum Crossover) 100 watts
Resonance Frequency (Fs) 700 Hz
Frequency Range 700 Hz – 32,000 Hz, +/- 3 dB
Sensitivity 93.5 dB at 2.83V/1meter
Impedance 4Ω
DC Resistance 3.6Ω
Voice Coil Diameter 25.5 mm (1-inch)
Qms 2.842
Qes 2.113
Qts 1.212
Krm 175.5 nΩ
Erm 1.325
Kxm 14.545 µH
Exm 1.004
