Type / Name
VL62 VL262 VL122 VL152 VL212 Sub18 Sub28
Order-# D113127 D113101 D113103 D113104 D113133 D113129 D113130
Cabinet Full-Range Full-Range Full-Range Full-Range Full-Range Subwoofer Subwoofer
Configuration passive 2-Way passive 2-Way passive 2-Way passive 2-Way passive 2-Way Vented Direct Vented Direct
or Biamped Mode or Biamped Mode or Biamped Mode Radiator Radiator
Nominal Impedance 16 ohms 8 ohms 8 ohms 8 ohms 4 ohms 8 ohms 4 ohms**
Rated Power RMS 150 watts 300 watts 400 watts 500 watts 800 watts 700 watts 1400 watts
Program Power 300 watts 600 watts 800 watts 1000 watts 1600 watts 1400 watts 2800 watts
Peak Power 600 watts 1200 watts 1600 watts 2000 watts 3200 watts 2800 watts 5600 watts
SPL 2,83 V/1m 94 dB* 97 dB 99 dB 100 dB 105 dB 98 dB 104 dB
max. SPL 1m
(calc. with Peak) 122 dB 125 dB 131 dB 133 dB 137 dB 132 dB 138 dB
Freq. Range (-10 dB) 90Hz - 20Hz 90Hz - 20Hz 60Hz - 20Hz 50Hz - 20Hz 80Hz - 20Hz 35Hz - 700Hz 35Hz - 700Hz
Coverage Angle nom. 90° x 40° 90° x 40° 90° x 45° 90° x 45° 90° x 45° --- ---
Passive
X-Over Frequency 2,2 kHz 2,2 kHz 1,5 kHz 1,5 kHz 1,5 kHz Hi-Cut Hi-Cut
VCT Protections Halogen Halogen yes yes yes yes yes
Components HIGH Ev DH 3 Ev DH 3 Ev ND6-8 Ev ND6-8 Ev ND6-8 --- ---
Order-# D353078 D353078 D361493 D361493 D361493 --- ---
Components LOW DND 6130-16 2x DND 6130-16 DND 12350 DND 15400 2x DND 12350 LFS 18700 2x LFS 18700
Order-# D366420 D366420 D366559 D366303 D366559 D366304 D366304
Connectors SPEAKON 2x NL 4MPR 2x NL 4MPR 2x NL 4MPR 2x NL 4MPR 2x NL 4MPR 2x NL 4MPR 2x NL 4MPR
Pin Wiring
Normal/Fullrange
1+/1- 1+/1- 1+/1- 1+/1- 1+/1- 1+/1- 1+/1-
Pin Wiring Biamped HF --- --- 2+/2- 2+/2- 2+/2- --- Speaker A 1+/1-
Pin Wiring Biamped LF --- --- 1+/1- 1+/1- 1+/1- --- Speaker B 2+/2-
Dimensions
(WxHxD) mm
217x 379x 230 217x 543x 230 385x 715x 374 441x 780x 407 385x 1035x 374 505x 805x 570 605x 1205x 675
Net Weight 8 kg 10 kg 24 kg 26 kg 34 kg 49 kg 82 kg
Enclosure Material Birch Plywood Birch Plywood
Finish Black 2-Component Structure Paint Black 2-Component Structure Paint
Grille Powder Coated Steel, Acoustic Foam Powder Coated Steel
Warranty 36 months 36 months 36 months 36 months 36 months 36 months 36 months
* 4,0 V = 1W @ 16 ohms **switchable 1x 4 ohms / 2x 8 ohms
