2063 Assembly Page - 12
H A R D W A R E L I S T I N G
A S S E M B LY
C A T A L O G
Key # Qty Part Number Description
A 4 11-BTN-123WZ 1/2"-13 x 3" BUTTON HEAD
B 4 11-HEX-125WZ 1/2"-13 x 5" HEX HEAD
C 32 11-SET-10(32)18 10-32 x 1/8" SET SCREW
AA 16 13-FLT-12SAEWZ 1/2" FLAT WASHER
BA 8 12-LOK-12WZ 1/2" LOCK NUT
CA 4 26-STD-SM323 1 1/4" DIA x 3/4" ALUMINUM CAP
CB 4 26-STD-SM324 1 1/4" DIA x3/8" ALUMINUM RING
CC 2 26-STD-PLAS206-9 1.175" OD x .9375 x 5.5" LG GRIP
CD 2 26-STD-PLAS206-16 1.175" OD x .9375 x 13.75" LG GRIP
CF 4 26-STD-SM391 1 1/2" Dia x 3/4" ALUMINUM CAP
CG 4 26-STD-SM392 1 1/2" DIA x 3/8" ALUMINUM RING
CH 2 26-STD-PLAS235-4 1.425" OD x 1.188" ID x 5.50 LG GRIP
CJ 2 26-STD-PLAS235-6 1.425" OD x 1.188" ID x 13.75 LG GRIP
