Owner's manual, Frame assembly, Page 45 v-select assembly – Hoist Fitness V-SELECT User Manual
Page 46
121
GUARD BOLT
47
19
110
94
32
94
110
BOLT (110) AS SHOWN
CABLE (32) IS FED THROUGH
THE FRAME (19) IN PREVIOUS
STEPS AS SHOWN
47
47
47
19
GUARD BOLT
BE SURE TO POSITION
CABLE (32) BETWEEN
PULLEY (47) AND GUARD
32
OWNER'S MANUAL
PAGE 45
V-SELECT ASSEMBLY
REMOVED FOR CLARITY.
SAME TIME.
- INSTALL CABLE AND PULLEYS AT THE
FRAME ASSEMBLY
NOTE:
- WRENCH TIGHTEN HARDWARE.
- SOME PARTS MAY HAVE BEEN
