Page 49
JAM NUT
14
53
5
JAM BOLT
5
OWNER'S MANUAL
V-ELITE ASSEMBLY
PAGE 48
WARNING - CABLE BOLT MUST BE THREADED
A MINIMUM OF 3/8" WITH JAM NUT TIGHTENED
SECURELY TO ENSURE PROPER CONNECTION.
LOOSEN JAM NUT AND THREAD
BOLT IN/OUT TO GIVE THE CABLE
PROPER TENSION. RE-TIGHTEN
JAM NUT.
FINE TUNING:
FRAME ASSEMBLY
NOTE:
- SOME PARTS MAY HAVE BEEN
REMOVED FOR CLARITY.
- INSTALL CABLE AND PULLEYS AT THE
SAME TIME.
- WRENCH TIGHTEN CABLE ASSEMBLY
(5) TO SECURE ONTO (14).
