Page 18
ITEM NO.
PART NUMBER
DESCRIPTION
QTY.
1
026-01X1411
U-JOINT ASSEMBLY
2
2
026-01X3211
LEFT ARTICULATING HANDLE ASSEMBLY
1
3
026-01X3212
RIGHT ARTICULATING HANDLE ASSEMBLY
1
4
026-01X4051
PRESS ARM ASSEMBLY
1
5
026-01X5083
PRESS ARM HANGER ASSEMBLY
1
6
011-0111008
SET SCREW: 1/4"-28 X .25" LG. (WZ)
8
7
014-0019005-1
T SPLIT COLLAR THREADED 1.00" I.D. X 20mm
4
8
014-0101002
BUSHING: OILITE FLANGED Ø.75" O.D X Ø.50" I.D X .38" LG.
8
9
014-0101005
BUSHING: OILITE FLANGED Ø1.38" O.D. X Ø1.00" I.D. X .81" LG.
2
10
016-0101017
END CAP
2.00" X .120" WALL (GRAY)
2
11
019-0001001
PLUG BUMPER
2
12
019-0002050
GRIP CLOSED END
1.00" X 17.50" LG.
2
13
026-01M0932
END CAP: ALUMINIUM
1.25" ID
2
14
026-01M0933
ALUMINUM RING:
1.25" ID
2
15
026-01M0936
ALUMINIUM RING:
1.00" I.D.
2
16
026-01M2550
PULL PIN CAP
1
17
026-01M2267
SHAFT:
1.00" X 9.44"
1
18
026-01P6136
FIXED PLATE
1
19
026-01PL198
HANDLE CLIP
2
20
026-01PL0235-15
GRIP OPEN END
1.25" X 11.00 LG.
2
21
026-01PL0382
DUAL STEM PLUG BUMPER - BLACK
1
22
013-0002003
1/4" X 16mm SAE FLAT WASHER (WZ)
2
23
013-0402007
3/8" X 22mm FLAT WASHER (WZ)
4
24
013-0102003
1/2" X 27mm SAE FLAT WASHER (WZ)
8
25
013-0102023
1/4" INTERNAL LOCK WASHER
2
26
011-0007097
1/4"-20UNC X .75" SHCS (BZ)
8
27
011-0101025
1/4"-20UNC X 1.00" BHCB (WZ)
2
28
011-0002049
3/8"-16UNC X .75" FHCS (WZ) W/NYLON PATCH
2
29
011-0107020
3/8"-16UNC X 3.25" HHB (WZ)
2
30
011-0407024
1/2"-13UNC X 2.75" HHB (WZ)
4
31
012-0104008
3/8"-16 UNC THIN NYLOCK NUT (WZ)
2
32
012-0304011
1/2"-13 UNC THIN NYLOCK NUT (WZ)
4
33
021-0003307
DECAL DO NOT HANG (LAT AREA) 1.63" X 2.50"
1
34
021-0003669
DECAL: V3 BADGE
1
35
SERIAL # DECAL
DECAL HOIST SERIAL # 1.63" X 2.63"
1
36
016-0201007
END CAP
1.00" (BLACK)
2
PART LIST
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
OWNER'S MANUAL
PAGE 17
V3-PRESS ARM ASSEMBLY
