Page 12: Rs-1102-a assembly
- SOME PARTS MAY HAVE BEEN
REMOVED FOR CLARITY.
NOTE:
- WRENCH TIGHTEN ALL HARDWARE.
- INSTALL CABLE AND PULLEYS AT THE
SAME TIME.
- REPEAT CABLE ASSEMBLY FOR
OPPOSITE SIDE.
FRAME ASSEMBLY
PAGE 11
OWNER'S MANUAL
RS-1102-A ASSEMBLY
46
25
59
83
94
89
6
87
92
90
87
89
63
59
67
25
90
67
NOTE:
BE SURE CABLE (67) RUNS
BETWEEN CABLE PULLEY (25)
AND GROOVED WHEEL (90).
AS SHOWN
PROPERLY INSTALLED VIEW
