Part list continued, Owner's manual – Hoist Fitness RPL-5601 User Manual
Page 19
ITEM NO.
PART NUMBER
DESCRIPTION
QTY.
41
012-0102012
1/2"-20 FLANGED NUT (WZ)
1
42
014-0009007
BEARING: FLANGED Ø2.00" O.D. X Ø1.00" I.D.
4
43
014-0012010
BEARING: FLANGED BEARING Ø2.50" O.D. X Ø1.39" I.D.
4
44
014-0101002
BUSHING: OILITE FLANGED Ø.75" O.D X Ø.50" I.D X .38" LG.
2
45
014-0013003
1/2-20 LH, MALE ROD END
1
46
014-0013001
1/2-20 FEMALE ROD END
1
47
014-0024001
THRUST WASHER, 1"
2
48
014-0101017
BUSHING: OILITE FLANGED Ø1.00" ID X Ø1.38" OD X .75" LG.
2
49
014-10012001
THRUST BEARING, 1"
1
50
016-0201041
3.00" END CAP .06" WALL (BLACK)
1
51
019-0001003
BUMPER,
1.50" X .625" T
4
52
020-0011009
SPRING
1
53
011-0107055
1/4"-20UNC X .75" HHB (WZ)
2
54
011-0101030
5/16"-18UNC X 1.00" BHCS (WZ)
5
55
011-0107011
5/16"-18UNC X 1.25" HHB (WZ)
6
56
011-0201003
3/8"-16UNC X 1.00" BHCS (BZ)
2
57
011-0101026
3/8"-16UNC X 1.00" BHCS (WZ)
8
58
011-0002044
3/8"-16UNC X 1.00" FHCS (WZ) W/NYLON PATCH
1
59
011-0101034
3/8"-16UNC X 1.25" BHCS (WZ)
2
60
011-0407026
3/8"-16UNC X 3.00" HHB (WZ)
4
61
011-0407055
1/2"-13UNC X 4.75" HHB (WZ)
3
62
011-0102030
1/2"-13UNC X 5.25" HHB (WZ)
1
63
013-0002003
1/4" X 16mm SAE FLAT WASHER (WZ)
4
64
013-0302008
5/16" SAE FLAT WASHER (WZ)
14
65
014-0011001
NYLINER BUSHING: Ø 1.09" O.D. X Ø 1.00" I.D X 1.13" LG.
2
66
013-0402007
3/8" X 22mm FLAT WASHER (WZ)
24
67
013-0303003
3/8" FENDER WASHER (BZ)
2
68
013-0102003
1/2" X 27mm SAE FLAT WASHER (WZ)
11
69
012-0104009
1/4"-20 UNC THIN NYLOCK NUT (WZ)
2
70
013-0102021
5/16" SPLIT WASHER (WZ)
4
71
013-0102020
3/8" SPLIT LOCK WASHER (BZ)
2
72
013-0102022
3/8" INTERNAL LOCK WASHER
10
74
012-0104008
3/8"-16 UNC THIN NYLOCK NUT (WZ)
8
75
012-0304011
1/2"-13 UNC THIN NYLOCK NUT (WZ)
1
76
011-0107009
3/8"-16UNC X 2.50" HHB (WZ)
4
77
011-0107029
5/16"-18UNC X 1.00" HHB (WZ)
8
78
021-0003559
ROC-AB PLACARD (LEFT)
1
79
021-0003569
ROC-AB PLACARD (RIGHT)
1
80
021-0003570
ROC-AB DECAL PLACARD (BACK)
1
81
021-0003135
DECAL WARNING 1.50" X 6.69"
1
PART LIST CONTINUED
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
OWNER'S MANUAL
PAGE 18
RPL-5601 ASSEMBLY
