background image

ITEM NO.

PART NUMBER

DESCRIPTION

QTY

1

026-01PL2236

TOP CAP W/INSERTS

1

2

026-01X3294

REAR UPRIGHT LEFT ASSEMBLY

1

3

026-01X3377

REAR UPRIGHT RIGHT ASSEMBLY

1

4

026-01X2402

FOOT PLATE ASSEMBLY

2

5

026-01X2849

RACHET PULL-PIN ASSEMBLY

1

6

026-01X2975

FOOT PLATE MOUNT ASSEMBLY

2

7

026-01X3235

CENTER UPRIGHT

1

8

026-01X3287

SHAFT, LIFT-ARM ASSEMBLY

1

9

026-01X3292

LIMITING STOP ASSEMBLY

1

10

026-01X3305

WEIGHT HORN ASSEMBLY

2

11

026-01X3308

LINK ASSEMBLY

2

12

026-01X3404

LIFT ARM DECLINE

1

13

026-01X3409

BASE FRAME ASSEMBLY

1

14

026-01X3411

PRESS ARM RIGHT

1

15

026-01X3412

PRESS ARM LEFT

1

16

026-01X3413

PRESS ARM LINKS

2

17

026-01X3414

LINK MOUNT - LEFT

1

18

026-01X3416

TIE-ROD END LEFT HANDED

2

19

026-01X3417

LINK MOUNT - RIGHT

1

20

026-01X3420

TIE-ROD END RIGHT HANDED

2

21

026-01X2387

SEAT PAD ASSEMBLY

1

22

026-01X3429

USER SUPPORT FRAME ASSEMBLY

1

23

022-01PD2054-A

SEAT PAD ASSEMBLY

1

24

022-01PD2055

UPHOLSTERED HEAD PAD

1

25

022-01PD2058

UPHOLSTERED BACK PAD

1

26

011-0111008

SET SCREW: 1/4"-28 X .25" LG. (WZ)

4

27

012-0202001

1/2"-13 FLANGED NUT (WZ)

1

28

012-0105009

12 mm JAMNUT RH

2

29

012-0105010

12 mm JAMNUT LH

2

30

014-0019005-2

SPLIT COLLAR: 1.00" I.D. X 20mmT NON-THREADED

1

31

014-0009007

BEARING: FLANGED Ø2.00" O.D. X Ø1.00" I.D.

4

32

014-0005001

BEARING: (SMALL) Ø1.37" O.D. X Ø.75" I.D.

4

33

014-0012013

BEARING: BALL BEARING Ø2.44" O.D. X Ø1.18" I.D.

4

34

016-0001003

END CAP 1.50" X 2.50" (BLACK)

1

35

022-01PD2058-5

PLASTIC BACK PAD BACKING

1

PART LIST

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED

PAGE 33

OWNER'S MANUAL

RPL-5305 ASSEMBLY
