OWNER'S MANUAL
RPL-5303 ASSEMBLY
PAGE 34
PART LIST CONTINUED
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
ITEM NO.
PART NUMBER
DESCRIPTION
QTY
36
026-01F0251
BRACKET PLATE: 2 HOLES 7.00" X 2.75"
1
37
026-01F0316
8" FLNG.
1
38
026-01M0660
SHAFT Ø1.00" O.D. X Ø .52" I.D. X 4.69" LG.
1
39
026-01M0927
SHAFT Ø.75" O.D. X Ø.52" I.D. X 3.82" LG.
2
40
026-01M0932
END CAP: ALUMINIUM Ø1.25" ID
2
41
026-01M0933
ALUMINUM RING: Ø1.25" ID
2
42
026-01M1185
WEIGHT HORN SHAFT 15.00"LG.
4
43
026-01M2356
END CAP: DOMED Ø 2.75" O.D.
2
44
026-01P2920
HEAD BRACKET MOUNT
1
45
026-01P2925
PAD MOUNT BRACKET
2
46
026-01PL0125
E-Z GLIDE PLASTIC SLEEVE
2
47
026-01PL0235-33
Ø1.188" X 14.17" OPEN END GRIP
2
48
026-01PL0264
WEIGHT HORN RUBBER DONUT
2
49
026-01PL2122
OVAL-SHAPED RUBBER FOOT
1
50
026-01PL2131
D-SHAPED RUBBER FOOT
2
51
026-01PL2197
PLASTIC SCUFF GUARD 11.05" LG.
1
52
026-01PL2200
PINETREE PLUG
1
53
026-01PL2246
DUAL HOLE BUMPER 2.05" THICK
3
54
026-01PL2313
WEIGHT HORN RUBBER DONUT W/ 3.75 COPE
4
55
013-0002003
1/4" X 16mm SAE FLAT WASHER (WZ)
2
56
013-0302008
5/16" SAE FLAT WASHER (WZ)
10
57
013-0402007
3/8" X 22mm FLAT WASHER (WZ)
32
58
013-0102003
1/2" X 27mm SAE FLAT WASHER (WZ)
36
59
013-0102023
1/4" INTERNAL LOCK WASHER
2
60
013-0102022
3/8" INTERNAL LOCK WASHER
14
61
013-0408001
3/8" INTERNAL LOCK WASHER (SS)
2
62
013-0302014
1/2" INTERNAL LOCK WASHER
4
63
011-0007097
1/4"-20UNC X .75" SHCS (BZ)
2
64
011-0101122
1/4"-20UNC X 2.50" BHCS (WZ) w/ NYLON PATCH
2
65
011-0107029
5/16"-18UNC X 1.00" HHB (WZ)
8
66
011-0101030
5/16"-18UNC X 1.00" BHCS (WZ)
1
67
011-0107011
5/16"-18UNC X 1.25" HHB (WZ)
2
68
011-0311013
3/8-16UNC X .75" SQUARE HEAD (WZ)
1
69
011-0101026
3/8"-16UNC X 1.00" BHCS (WZ)
16
70
011-0407022
3/8"-16UNC X 1.00" HHB (WZ)
1
