Owner's manual, Frame assembly, Page 15 – Hoist Fitness RPL-5301 User Manual
Page 18: Rpl-5301 assembly
JAM NUT (LH)
- HAND TIGHTEN HARDWARE.
PAGE 15
- SOME PARTS MAY HAVE BEEN
OWNER'S MANUAL
REMOVED FOR CLARITY.
RPL-5301 ASSEMBLY
NOTE:
FRAME ASSEMBLY
WARNING - TIE ROD ENDS (19, 20) MUST BE THREADED
A MINIMUM OF 3/8" WITH JAM NUT (26, 27) TIGHTENED
SECURELY TO ENSURE PROPER CONNECTION.
19
27
TIE ROD END (LH)
16
JAM NUT (RH)
26
20
TIE ROD
27
26
16
19
20
TIE ROD END (RH)
