Hoist Fitness RPL-5203 - Manual (Page 40)

ITEM NO. PART NUMBER DESCRIPTION QTY.
71 011-0101063 3/8"-16UNC X 1.00" SHCS (WZ) 4
72 011-0101026 3/8"-16UNC X 1.00" BHCS (WZ) 12
73 011-0101034 3/8"-16UNC X 1.25" BHCS (WZ) 6
74 011-0101049 3/8"-16UNC X 2.50" BHCS (WZ) 4
75 011-0407022 3/8"-16UNC X 1.00" HHB (WZ) 1
76 011-0407042 1/2"-13UNC X 1.00" HHB (WZ) 4
77 011-0407018 1/2"-13UNC X 2.50" HHB (WZ) 2
78 011-0407016 1/2"-13UNC X 3.00" HHB (WZ) 2
79 011-0407000 1/2"-13UNC X 3.50" HHB (WZ) 2
80 011-0407047 1/2"-13UNC X 4.00" HHB (WZ) 2
81 011-0207030 1/2"-13UNC X 4.50" HHB (WZ) 2
82 011-0107014 1/2"-13UNC X 5.00" HHB (WZ) 4
83 011-0107036 1/2"-13UNC X 5.75" HHB (WZ) 2
84 011-0307060 1/2"-13UNC X 6.00" HHB (WZ) 1
85 011-0107067 1/2"-13UNC X 7.75" HHB (WZ) 1
86 012-0105009 12 mm JAMNUT RH 2
87 012-0105010 12 mm JAMNUT LH 2
88 012-0104013 12mm THICK NYLOCK NUT (WZ) 4
89 012-0104008 3/8"-16 UNC THIN NYLOCK NUT (WZ) 13
90 012-0304011 1/2"-13 UNC THIN NYLOCK NUT (WZ) 26
91 021-0003008 DECAL COMMERCIAL MAINTENANCE 1.50" X 6.69" 1
92 021-0003113 DECAL PINCH POINT 1.63" X 3.25" (VERTICAL) 1
93 021-0003135 DECAL WARNING 1.50" X 6.69" 1
94 021-0003230 DECAL HOIST 1.63" X 5.93" 1
95 021-0003320 DECAL 800 LB. WEIGHT RATING (1.63" X 1.63") 1
96 021-0003334 DECAL HOIST 3.90" X 14.25" 2
97 021-0003341 DECAL PINCH POINT 1.07" X 2.13" (HORIZONTAL) 2
98 021-0003405 DECAL ROX 2
99 021-0003692 RPL-5203 SEATED MID-ROW PLACARD 1
100 021-0018022 DECAL HOISTFITNESS.COM LOGO 1
101 SERIAL # DECAL DECAL HOIST SERIAL # 1.63" X 2.63" 1
102 016-0001003 END CAP 1.50" X 2.50" (BLACK) 1
103 013-0001003 .50" CAP WASHER 4
104 016-0003001 .50" CAP WASHER CAP 4
105 021-0003730 DECAL ADJUST 1-9 (HORIZONTAL) 1
106 021-0004032 DECAL ADJUST 1-7 VERTICAL TXT. 1
107 026-01PL2247 PLASTIC SCUFF GUARD 5.60" ANGLED 2
PART LIST CONTINUED
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
PAGE 39
OWNER'S MANUAL
RPL-5203 ASSEMBLY
