FRAME ASSEMBLY
STEP 3
ITEM NO. PART NUMBER DESCRIPTION
1 026-01X2493 BASE ASSEMBLY
2 026-01X2495 TUBE ADJUSTOR ASSEMBLY
3 026-01X2496 HANDLE ASSEMBLY
7 026-01X0185 PULL-PIN ASSEMBLY
9 026-01P2564 LINK
17 016-0201023 END CAP 1.50" (BLACK)
18 014-0101002 OILITE FLANGED
20 019-0002003 1.50" X 6.00" LG. CLOSED END FOAM GRIP
31 013-0402007 3/8" X 22mm FLAT WASHER (WZ)
33 013-0102028 3/8" CURVED WASHER (WZ)
34 013-0102003 1/2" X 27mm SAE FLAT WASHER (WZ)
37 011-0407022 3/8"-16UNC X 1.00" HHB (WZ)
39 011-0407058 3/8"-16UNC X 2.00" HHB (WZ)
40 011-0407024 1/2"-13UNC X 2.75" HHB (WZ)
42 012-0104008 3/8"-16UNC THIN NYLOCK NUT (WZ)
43 012-0304011 1/2"-13UNC THIN NYLOCK NUT (WZ)
