ITEM NO. PART NUMBER DESCRIPTION QTY.
1 026-01X2801 MAIN FRAME ASSEMBLY 1
2 026-01X2803 LEG ASSEMBLY (LEFT) 1
3 026-01X2804 LEG ASSEMBLY (RIGHT) 1
4 026-01X0185 PULL-PIN ASSEMBLY 2
5 022-01PD2017-A UPHOLSTERY PAD W/VINYL BACKING 1
6 016-0201022 END CAP 2.00" (BLACK) 4
7 019-0002002 CLOSED END GRIP 2.00" 4
8 026-01M1071 FLNG SPACER - .156" THICK FLNG 4
9 026-01PL2172 COVER - BLACK 2
10 SERIAL # DECAL DECAL SERIAL # 1.63" X 2.63" 1
11 021-0003222 DECAL "H" 1.81" X 2.50" 2
12 021-0003223 DECAL NOT FOR COMMERCIAL USE 1.63" X 3.25" (VERTICAL) 1
13 021-0003227 500 LB. WEIGHT RATING DECAL (1.625" X 1.625") 1
14 021-0003230 DECAL HOIST 1.63" X 5.93" 1
15 021-0003138 DECAL PINCH POINT 1.63" X 2.63" (HORIZONTAL) 1
16 011-0101080 5/16"-18UNC X .75" BHCS (WZ) 4
17 011-0101109 3/8"-16UNC X 4.25" BHCS (WZ) 2
18 013-0302008 5/16" USS FLAT WASHER (WZ) 4
19 013-0102027 CUSTOM WASHER OD .631", ID .406" (WZ) 4
20 012-0104008 3/8"-16UNC THIN NYLOCK NUT (WZ) 2
PAGE 09
OWNER'S MANUAL
HF4164 ASSEMBLY
PART LIST
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
