PART LIST
PAGE 12
OWNER'S MANUAL
CF-3550 ASSEMBLY
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 026-01X3285 MAIN FRAME ASSEMBLY 1
2 026-01X3356 SEAT ADJUSTER ASSEMBLY 1
3 026-01X3286 SEAT ASSEMBLY 1
4 026-01X3160 RATCHET PULL-PIN ASSEMBLY 1
5 022-01PD2097-B ARM PAD ASSEMBLY 1
6 022-01PD2054-B SEAT PAD ASSEMBLY 1
7 026-01X5603 BAR REST 2
10 026-01PL0125-125 E-Z GLIDE PLASTIC SLEEVE 2
11 026-01PL2506 ELLIPTICAL RUBBER FOOT W/ SIDE LIPS 3
13 026-01PL2516 SCUFF GUARD (CURVED) 8.63" LG. W/ RIVETS 1
14 021-0003008 DECAL COMMERCIAL MAINTENANCE 1.50 X 6.69 1
15 021-0003135 DECAL WARNING 1.50" X 6.69" 1
16 021-0003230 DECAL HOIST 1.625" X 6.0613" 3
17 021-0003341 DECAL PINCH POINT 1.07" X 2.13" (HORIZONTAL) 2
18 021-0004032 DECAL ADJUST 1-7 VERTICAL TXT. 1
19 SERIAL # DECAL DECAL HOIST SERIAL # 1.63" X 2.63" 1
20 011-0311013 3/8-16UNC X .75" SQUARE HEAD (WZ) 1
21 011-0101020 1/2"-13UNC X 1.00" BHCS (WZ) 4
22 011-0207030 1/2"-13UNC X 4.50" HHB (WZ) 2
23 011-0107011 5/16"-18UNC X 1.25" HHB (WZ) 6
24 013-0102003 1/2" X 27mm SAE FLAT WASHER (WZ) 8
25 013-0302008 5/16" SAE FLAT WASHER (WZ) 6
26 013-0903002 1/2" SPLIT LOCK WASHER (WZ) 4
27 012-0304011 1/2"-13 UNC THIN NYLOCK NUT (WZ) 2
28 013-0102007 5/16" INTERNAL LOCK WASHER (WZ) 6
29 026-01PL2351 PLASTIC SCUFF GUARD W/ RIVETS 2
