ITEM NO.

PART NUMBER

DESCRIPTION

QTY.

1

026-01F0300

FLANGE .188" H.R.S. 3.00" DIA.

1

2

026-01PL2122-B

OVAL-SHAPED RUBBER FOOT

3

3

013-0302008

5/16" SAE FLAT WASHER (WZ)

2

4

011-0107011

5/16"-18UNC X 1.25" HHB (WZ)

2

5

011-0107050

1/2"-13UNC X 3.75" HHB (WZ)

2

6

012-0304011

1/2"-13 UNC THIN NYLOCK NUT (WZ)

2

7

021-0003135

DECAL WARNING 1.50" X 6.69"

1

8

021-0003008

DECAL COMMERCIAL MAINTENANCE 1.50" X 6.69"

1

9

021-0003230

DECAL HOIST 1.63" X 5.93"

3

10

SERIAL # DECAL

DECAL SERIAL # 1.63" X 2.63"

1

12

013-0202007

1/2" CURVED WASHER (WZ)

4

13

026-01X3310

FOOT ASSEMBLY

1

14

022-01PD2203-A

SEAT PAD ASSEMBLY

1

15

026-01PL2306

SEAT PAD PLASTIC BACKING

1

16

026-01X5128

MAIN FRAME

1

17

019-0002015

GRIP: CLOSED END

1.00" X 6.00" LG.

1

18

016-0201007

END CAP

1.00" (BLACK)

1

19

021-0003229

DECAL 1000 LB. WEIGHT RATING 1.63" X 1.63"

1

PAGE 11

OWNER'S MANUAL

CF-3950 ASSEMBLY

PART LIST

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
