ITEM NO. PART NUMBER DESCRIPTION QTY.
1 026-01X5165 MAIN FRAME ASSEMBLY 1
2 026-01X5166 SIDE UPRIGHT 2
3 026-01M2278 WEIGHT PEG 12.38" LG. 12
4 026-01PL2122-B OVAL-SHAPED RUBBER FOOT 4
5 026-01PL2313 WEIGHT HORN RUBBER DONUT W/ 3.75 COPE 12
6 013-0102003 1/2" X 27mm SAE FLAT WASHER (WZ) 8
7 013-0102022 3/8" INTERNAL LOCK WASHER 12
8 011-0101027 3/8"-16UNC X 1.50" BHCS (WZ) 12
9 011-0101051 1/2"-13UNC X 1.25" BHCS (WZ) 2
10 011-0407016 1/2"-13UNC X 3.00" HHB (WZ) 2
11 012-0304011 1/2"-13 UNC THIN NYLOCK NUT (WZ) 4
12 013-0402007 3/8" X 22mm FLAT WASHER (WZ) 12
13 021-0003008 DECAL COMMERCIAL MAINTENANCE 1.50" X 6.69" 1
14 021-0003135 DECAL WARNING 1.50" X 6.69" 1
15 021-0003230 DECAL HOIST 1.63" X 5.93" 2
16 SERIAL # DECAL DECAL HOIST SERIAL # 1.63" X 2.63" 1
PART LIST
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
PAGE 11
OWNER'S MANUAL
CF-3444 ASSEMBLY
