OWNER'S MANUAL
PAGE 15 CF-3177 ASSEMBLY
PART LIST
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 CF OLYMPIC BENCH UPRIGHTS OLYMPIC BENCH UPRIGHTS 1
2 026-01X4014 BASE FRAME ASSEMBLY 1
3 026-01X3160 RACHET PULL-PIN ASSEMBLY 1
4 026-01X3224 ROLLER BAR ASSEMBLY 1
5 026-01X3226 SELF-ALIGNING ROLLER BAR ASSEMBLY 1
6 022-01PD2093-A SEAT PAD ASSEMBLY 1
7 022-01PD2205-A HEAD PAD ASSEMBLY 1
8 022-01PD2207-A BACK PAD ASSEMBLY 1
9 022-01PDR018 ROLLER PAD 5.00" X 8.00" LG. 4
10 014-0101002 FLANGED OILITE .75" O.D X .50" I.D X .38" LG. 2
11 026-01M0238 FLATHEAD CAP 2.00" ALUM. 4
12 026-01M0932 1.25" ID END CAP ALUMINIUM 1
13 026-01P3497 DECLINE RACKOUT PLATE 2
14 026-01P3548 .125" BRACKET PLATE 1
15 026-01PL0125-125 E-Z GLIDE PLASTIC SLEEVE 2
16 026-01PL0235-15 OPEN END GRIP 1.25" X 11.00" LG. 1
17 026-01PL0310 PLASTIC BUSHING 8
18 026-01PL2211-B RUBBER FOOT 1
19 026-01PL2220 SEAT PAD PLASTIC BACKING 1
20 026-01PL2305 HEAD PAD PLASTIC BACKING 1
21 026-01PL2309 BACK PAD PLASTIC BACKING 1
22 021-0003544 DECAL ADJUST 1-5 VERTICAL TXT. 1
23 021-0003512 DECAL PINCH POINT 1.175" X 1.35" (TRIANGLE) 1
24 021-0003627 DECAL HOIST 2.12" X 7.75" 2
25 011-0311013 3/8-16UNC X .75" SQUARE HEAD (WZ) 1
26 011-0002048 3/8"-16UNC X 1.25" FHCS (WZ) W/NYLON PATCH 4
27 011-0107037 3/8"-16UNC X 1.25" BHCS (WZ) 1
28 011-0101070 1/2"-13UNC X 4.00" HHB (WZ) 4
29 011-0407035 1/2"-13UNC X 5.25" HHB (WZ) 1
30 011-0107011 5/16"-18UNC X 1.25" HHB (WZ) 10
31 013-0102003 1/2" X 27mm SAE FLAT WASHER (WZ) 10
32 013-0302008 5/16" SAE FLAT WASHER (WZ) 10
33 013-0102022 3/8" INTERNAL LOCK WASHER 1
34 012-0304011 1/2"-13 UNC THIN NYLOCK NUT (WZ) 5
35 026-01M0933 1.25" ID ALUMINUM RING 1
36 011-0311005 10-32 X 1/8" SET SCREW 2
37 SERIAL # DECAL DECAL HOIST SERIAL # 1.63" X 2.63" 1
