FRAME ASSEMBLY
NOTE:
- WRENCH TIGHTEN HARDWARE
- WRENCH TIGHTEN ALL PREVIOUSLY
HAND TIGHTENED HARDWARE.
OWNER'S MANUAL
CF-3252 ASSEMBLY
PAGE 10
*IMPORTANT*
NOW THAT THE CF-3252 FRAME IS COMPLETELY ASSEMBLED, TAKE TIME TO
ASSURE THAT YOUR UNIT IS ASSEMBLED SQUARE AND PERPENDICULAR. IF NOT,
IT WILL BE NECESSARY TO LOOSEN SOME FRAME HARDWARE TO RE-ALIGN THE
FRAME ANDRETIGHTEN BOLTS.
