background image

The ImagePro 8770 is a portable LCD projector that

can be used in a variety of applications. With sufficient

brightness for most classrooms and conference rooms

the 8770 is designed to be reliable and easy to

maintain and operate.
The ImagePro 8770 also

has a built-in transition

detector that prevents poten-

tial thieves from removing

the projector from a ceiling

mount without the correct PIN code.

Dukane Corporation

Audio Visual Products Division

2900 Dukane Drive

St. Charles, Illinois 60174

Toll-free: 800-676-2485

Fax: 630-584-5156

[email protected]

www.dukcorp.com/av

ImagePro 8770

Portable LCD projector

Specifications 8770

Image Element

0.63” polysilicon active-matrix TFT x3

Brightness

2000 ANSI lumens

(1600 lumens in Whisper Mode)

Resolution

1024 x 768 pixels (H X V), XGA

Contrast

500:1

Scanning Frequency

fh 15 -106 kHz, fv 50-120 Hz

Lens

Manual zoom (F1.7 – 1.9), 1.2X

Lens Throw Ratio

1.3 –1.5:1 throw distance to

image width

Keystone Correction

Digital, vertical +/-30 deg

Aspect Ratio

4:3, 16:9 selectable

Computer

VGA, SVGA, XGA, SXGA, SXGA+,

UXGA

Compatibility

Compressed PC and MAC13” and

MAC16”

Video Compatibility

NTSC, NTSC4.43, PAL, SECAM,

PAL-M, PAL-N,

Component Video,

HDTV (1080i, 720p, 576i, 480i)

Image Control

Freeze function, electronic

magnification and pan

Mouse Control

Using USB

Projection Modes

Front/rear/ceiling

Color Reproduction

24 bit (16.7 million)

Lamp

160W UHB (90-day limited warranty)

Lamp Life

2000 hours (typical) 3000 hours

(whisper mode)

Audio

1 speaker 1 watt

Throw Distance

30” to 368”

Screen Size, diagonal

30” to 300”

Inputs, Video

(1) Component, Shared on 15 pin D-Sub

(1) S-video, Mini DIN 4-pin

(1) Composite video, RCA x 1

Inputs, Computer

(2) RGB, 15 pin D-sub

Inputs, Audio

(2) Stereo mini jack

Outputs, Audio

(1) Stereo mini jack

Outputs, Monitor

RGB, 15 pin D-sub

Outputs, Control

RS-232, 9 pin D-sub

USB Mouse control

Security

Kensington lock slot

Fan Level

35dB, ultra quiet

29dB in Whisper Mode

Operating Temperature 41-95 deg F
Power

AC 100-120V, AC 220-240V

50/60 Hz, 250 watt

Size (WxHxD)

10.8” x 2.3” x 8.1”

Weight

3.9 lbs.

Shipping Weight

14 lbs.

Carton Size

16” x 14” x 12”

Accessories Included

Remote control, batteries, power cord,

RGB cable, RCA video cable,

Mini-RCA Audio adapter, operators

manual and soft carry case.

Safety

UL/C-UL, FCC Class B, CE

Optional Accessories

Lamp 456-8770

Ceiling Mount, Universal; RPA-U

Key features:

• XGA (1024 x 768) resolution
• 2000 lumen brightness
• 3 Polysilicon Active-Matrix LCDs
• Wide angle lens
• HDTV ready
• PIN Security Transition Detector
• Vertical keystone correction +/- 30°
• Easy to transport, only 3.9 lbs.
• Monitor loopthrough
• Remote mouse control
• Blackboard and whiteboard mode
• Five Year Warranty and One Year Peace of Mind Service

Five (5) year limited warranty on parts and labor in North America,

lamp excluded (for other locations, local warranties apply).Includes

Dukane’s FREE 1 year Peace-of-Mind Loaner Program.

5

YR

8770 Projection Table

Throw Ratio (distance to width), 1.3 1.5

#11742-B-07

ImagePro is a registered trademark of Dukane Corporation

Image Size 4:3

Throw Distance

Diagonal

Width

Min.

Max.

Inches

Inches

Feet

Feet

30

24

2.5

3.0

60

48

5.1

6.1

80

64

6.8

8.1

100

80

8.5

10.2

120

96

10.2

12.3

150

120

12.8

15.3

200

160

17.0

20.4

300

240

25.5

30.7
