PARTS LIST
This list contains replaceable parts used in your heater. When
ordering parts, follow the instructions listed under Replacement
Parts on page 30 of this manual.
PARTS LIST
VP10TA, VN10TA
KEY
PART NUMBER
NO.
VP10TA
VN10TA
DESCRIPTION
QTY.
1
098304-01
098304-01
Screw, #10 x 3/8"
2
2
**
**
Front Panel Assembly
1
3
099318-03
099318-03
Grill Guard
1
4
101108-01
101108-01
Grill Guard Clip
2
5
099275-01
099275-01
Reflector Assembly
1
6
M15823-37
M15823-37
Screw Hex #8 x 1/4"
10
7
099059-03
503329
ODS/Pilot Assembly
1
7-1
098514-01
098514-01
Thermocouple
1
7-2
098594-01
098594-01
Ignitor Electrode
1
8
099884-03
099884-03
Burner Assembly
1
9
099056-25
099056-24
Injector
2
10
104087-01
104087-01
Tubing - Burner
1
11
099387-11
099387-11
Pilot Tubing - Valve to pilot
1
12
M11084-26
M11084-26
Screw, #10 x 3/8"
2
13
104084-01
104084-01
Tubing - Inlet
1
14
098522-16
098522-16
Control Valve
1
15
097159-04
097159-04
Piezo Ignitor
1
16
098271-03
098271-03
Ignitor Cable
1
17
**
**
Cabinet Assembly
1
18
099415-18
099415-12
Gas Regulator
1
19
098303-02
098303-02
Screw, #6 x 5/16"
2
PARTS AVAILABLE - NOT SHOWN
100642-02
100642-02
Assembly, Hardware
1
** Not a field replaceable part.
