UNDERSTANDING LED INDICATORS
The front panel LEDs provides instant status feedback, and, helps
monitor and troubleshoot when needed.
Figure 6. LED indicators of the Switch
Power and System LEDs
POWER: Power Indicator
On
: When the Power LED lights on, the Switch is receiving power.
Off
: When the Power turns off or the power cord has improper connection.
CPU: Management Indicator
Blinking
: When the CPU is working, the System LED is blinking.
On/Off
: The CPU is not working.
