Dodge 2009 Caliber SRT4 User Manual
Page 355
Cavity Cartridge
Fuse
Mini-
Fuse
Description
10
20 Amp
Yellow
CCN Power Locks
11
15 Amp
Lt Blue
Power Outlet
12
20 Amp
Yellow
Ign Run/Acc Inverter
13
20 Amp
Yellow
Pwr run/Acc Outlet
RR
14
10 Amp
Red
IOD CCN/Interior
Lighting
15
40 Amp
Green
RAD Fan Relay Bat-
tery Feed
16
15 Amp
Lt. Blue
IGN Run/Acc Cigar
Ltr/Sunroof
17
10 Amp
Red
IOD Feed Mod-Wcm
Cavity Cartridge
Fuse
Mini-
Fuse
Description
18
40 Amp
Green
ASD Relay Contact
PWR Feed
19
20 Amp
Yellow
PWR Amp 1 and
Amp 2 Feed
20
15 Amp
Lt. Blue
IOD Feed Radio
21
10 Amp
Red
IOD Feed Intrus
Mod/Siren
22
10 Amp
Red
IGN RUN Heat/AC/
Compass Sensor
23
15 Amp
Lt. Blue
ENG ASD Relay Feed
3
24
15 Amp
Lt. Blue
Power Sunroof Feed
25
10 Amp
Red
Heated Mirror
MAINTAINING YOUR VEHICLE
353
7
