PARTS LIST
This list contains replaceable parts used in your heater. When
ordering parts, follow the instructions listed under Replacement
Parts on page 18 of this manual.
PARTS LIST
Models REM10PT and RH10PT
KEY
PART NUMBER
NO.
REM10PT
RH10PT
DESCRIPTION
QTY.
1
098304-01
098304-01
Screw, #10 x 3/8"
2
2
099467-03
099467-10
Front Panel Assembly
1
3
099318-04
099318-04
Grill Guard
1
4
101108-01
101108-01
Grill Guard Clip
2
5
102017-02
102017-02
Bottom Glass Retainer
1
6
098260-11
098260-11
Glass Panel
1
7
099319-02
099319-02
Top Glass Retainer
1
8
M11084-38
M11084-38
Screw, #8 x 3/8"
8
9
099317-02
099317-02
Deflector Unit
1
10
098271-09
098271-09
Ignitor Cable
1
11
098249-01
098249-01
Nut, M5
2
12
110803-02
110803-02
ODS/Pilot Assembly
1
13
104263-01
104263-01
Burner
1
14
099387-11
099387-11
Pilot Tubing
1
15
104259-06
104259-06
Injector, 1 Piece
1
16
NJF-8C
NJF-8C
Hex Nut
1
17
099415-18
099415-18
Pressure Regulator
1
18
104261-01
104261-01
Burner Tubing
1
19
104264-01
104264-01
Regulator Tubing
1
20
098522-18
098522-18
Thermostat Gas Valve
1
21
**
**
Cabinet
1
22
097159-04
097159-04
Piezo Ignitor
1
23
110701-01
110701-01
Elbow Fitting
1
24
098303-02
098303-02
Screw, #6 x 5/16"
2
PARTS AVAILABLE - NOT SHOWN
100642-02
100642-02
Assembly, Hardware
1
LPA3090
LPA3090
Hose/Regulator Assembly
1
** Not a field replacable part.
