17 102490
OWNER’S MANUAL
PARTS LIST
VN10T
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed
under Replacement Parts on page 15 of this manual.
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 098304-01 Screw, #10 x 3/8" 2
2 098454-06CD Front Panel 1
3 099318-03 Grill Guard 1
4 101108-01 Removable Speed Clip 2
5 099275-01 Reflector 1
6 M15823-37 Screw Hex #8 x 1/4" 10
7 503329 ODS/Pilot Assembly 1
7-1 098514-01 Thermocouple 1
7-2 098594-01 Ignitor Electrode 1
8 099884-02 Burner Assembly 1
9 099056-03 Injector 2
10 102491-01 Tubing - Burner 1
11 099387-11 Pilot Tubing - Valve to pilot 1
12 M11084-26 Screw, #10 x 3/8" 2
13 102517-01 Tubing - Inlet 1
14 098522-09 Control Valve 1
15 102445-01 Piezo Ignitor Service Kit 1
16 098271-03 Ignitor Cable 1
17 102571-02 Cabinet Assembly 1
18 099415-01 Gas Regulator 1
19 098303-02 Screw, #6 x 5/16" 2
PARTS AVAILABLE - NOT SHOWN
102471-01 Control Position Label 1
100642-02 Assembly, Hardware 1
