Super IO Configuration
Super IO Configuration
► Super IO Chip
This item shows the chip name which controls super IO devices.
Super Port 0 Configuration
► Serial Port
This item is used to enable or disable the serial port.
► Device Settings
This item shows the resource assigned to the serial port.
► Change Settings
This item is used to select an optimal settings for the serial port.
► Device Mode
This item is used to change the serial port mode. Options are: [Normal] and [High Speed].
Super IO Configuration
Super IO Chip IT8772 IT8772
Serial Port 0 Configuration
Serial Port [Enabled]
Device Settings IO=3F8h; IRQ=4;
Change Settings [Auto] [Auto]
Device Mode [Standard Serial Po...]
