5
88
5. A message prompts.
Press [Ctrl-Y] to erase the RAID array.
6. The configuration of LD1 array is completed.
Total size is 82.28+119.96+250.00+320.00 = 772.24GB
LD No RAID Mode Total Drv
LD 1 JBOD 4
Stripe Block: 64 KB Fast Init: ON
Gigabyte Boundary: ON Cache Mode: WriteThru
Channel :ID Drive Model Compatibilities Capacity(GB) Assignment
1 :Mas HDS728090PLA380 SATA 3G 42.28 Y
2 :Mas WDC WD1200JD-98HBB0 SATA 1.5G 79.96 Y
3 :Mas Hitachi HDT725025VLA3 SATA 3G 250.05 Y
4 :Mas ST3320620AS SATA 1.5G 320.07 Y
[↑] Up [↓] Down [ESC] Exit [Space] Change [Crtl-Y] SAVE [PgUp/Dn] Page Change
[ Define LD Menu ]
FastBuild (tm) Utility (c) 2007 Advanced Micro Devices, Inc.
[ Keys Available ]
[ Define LD Menu ]
Fast Initialization Option has been selected
It will erase the MBR data of the disks,
[ Define LD Menu ]
LD No RAID Mode Total Drv Capacity(GB) Status
LD 1 RAID 0 2 163.99 Functional
LD 2 −−−− −−−− −−−−−−−− −−−−
LD 3 −−−− −−−− −−−−−−−− −−−−
LD 4 −−−− −−−− −−−−−−−− −−−−
LD 5 −−−− −−−− −−−−−−−− −−−−
LD 6 −−−− −−−− −−−−−−−− −−−−
LD 7 −−−− −−−− −−−−−−−− −−−−
LD 8 −−−− −−−− −−−−−−−− −−−−
LD 9 −−−− −−−− −−−−−−−− −−−−
LD10 −−−− −−−− −−−−−−−− −−−−
[↑] Up [↓] Down [ESC] Exit [Enter] Select
FastBuild (tm) Utility (c) 2007 Advanced Micro Devices, Inc.
[ Keys Available ]
LD 1 JBOD 4 772.24 Functional
[ Define LD Menu ]
