7
Turbidity Detector Transducer Sensor
OR 42/3 ORT 4 ORG 12
OR 42/4 ORT 4 ORG 22
OR 52/3 ORT 5 ORG 12
OR 52/4 ORT 5 ORG 22
Types
■ With three ball valves, three screwed
unions and screwed-in vent nipple
■ Drying cartridge and turbidity standard
20 ppm (OR 52: also turbidity standard
40 TU/F*) are also supplied
■ Spare parts kit separately available, see
“Spare Parts”
*) TU/F = turbidity units of Formazin suspension
Design
Light emitter
At a flowrate of 2 l/min and V-shaped flow
through the sensor with a pipe length of 1 m
(DN 10 mm) and four bends: approx. 5 mbar
(
ζ
= 6.1)
Fluids
Water, condensate, drinks etc.
pH value
Up to 10.5 (a pH value of 11 and above will
lead to wear of the glass, depending on the
temperature)
Fluid temperature ranges
0 ... 60 °C with drying cartridge
60 ... 120 °C with vent nipple
Protection
IP 65
Max. ambient temperature
60 °C
Materials ORG 12 ORG 22
Cover flange GG-25 1.4580
Wetted parts 0.6025 1.4580
galvanized
Ball valves Ms 58 1.4436
Screwed unions St 1.4571
Glass cylinder Duran 50 Duran 50
O-rings EPDM EPDM
Housing 0.6025 0.6025
galvanized galvanized
Cleaning disc EPDM EPDM
Light emitter
Glow lamp 12 V/10 W BA 15 s
cable connection via 4 pole connector
Light receiver
Two silicon photo-electric cells,
cable connection via 4 pole connector
Approx. weight
6.8 kg
Dimensions
See Fig. 2
ENGLISH
Use oil and turbidity detector OR 42/OR 52
only for monitoring of transparent liquids to
detect any ingress of insoluble and
refracting foreign matter, for measuring of
turbidity and signal evaluation for indication
and recording as well as for tripping of
alarms, control valves etc.
The equipment must only be installed by
qualified staff.
Before installing the oil and turbidity detector
cut off power supply.
All repairs must be performed only by the
manufacturer. Misuse or any attempted
modification of the equipment will endanger
plant safety.
Important Safety Note
The terminal strip of the ORT4/ORT5 is live
during operation. This presents the danger
of electric shock. Cut off power supply
before opening the equipment or
undertaking any maintenance work
Warning
The oil and turbidity detector OR 42/OR 52
consists of the sensor ORG 12/ORG 22
and the measuring transducer ORT 4/
ORT 5.
Application:
■ In steam boiler plants: Monitoring of
condensate returned to the boiler for oil
and grease contamination, in particular
for boilers operating without constant
supervision acc. to TRD 604 (2 detectors
are required for 72 h operation)
■ For raw-water monitoring and water
treatment (sand filters, demineralization
plants, reverse-osmosis plants)
■ For waste-water monitoring
■ In breweries and the beverage industry
(filtration, monitoring of wort, quality
assurance etc.)
■ For salad oil production: Monitoring of
filtering process
■ For marine applications: Monitoring of
filtering equipment in accordance with
IMO (International Maritime Organization)
resolution MEPC.60(33) – when certain
cold cleaning agents that split up easily
are used which cannot form stable water/
oil emulsions
Purpose
The oil and turbidity detector measures the
intensity of the scattered light produced by
foreign matter that is not dissolved in trans-
parent liquids and exposed to incident light,
with emulsified oils scattering incident light
mainly in the forward direction.
In the oil and turbidity detector the forward
scattered-light principle is applied which
provides a high sensitivity for emulsified
greases and oils and other organic matter.
Operation
Approvals
■ Feedwater monitoring
TÜV – approval no. 09-96-0132
■ Feedwater monitoring in marine
applications GL 94855-94 HH
Seeberufsgenossenschaft
GL-OG-94-352002
■ 15 ppm oil detector for bilge monitoring in
engine rooms
GL 85486-94 HH
Seeberufsgenossenschaft
320023
Nominal size
DN 10, connections
3 / 8 "
BSP to DIN ISO 228
Nominal pressure
PN 10
Flowrate
0.5 ... 50 l/min
Technical Data ORG
Spare Parts
The spare parts kit for OR contains:
Designation Number
Glass cylinder 1
O-ring 25 x 3 2
O-ring 30 x 2 2
O ring 37 x 2 4
Glow lamp 2
For cleaning unit:
Cleaning plunger
1
Ring 1
Cleaning disc 1
Retaining ring 19 x 1.2 1
Fixing disc 1
