Checking the Open/Closed Settings
•
Valve Closed As you close the valve using the actuator, make
sure that the close light (green) illuminates just as the travel limit is
reached. The display should read 0% OPEN.
• Valve Open As you open the valve using the actuator, make sure that
the open light (red) illuminates just as the travel limit is reached. The
display should read 100% OPEN.
Setting the Password
At the ENtEr PasswOrd? prompt, use the black knob and toggle
to select the correct password. Another option in the Change Settings
menu is chaNgE PasswOrd? You may disable the actuator’s
password function by setting the password to 000. The password
function can be re-enabled by resetting the password to any other
three-digit code.
Before Y
ou Begin
0% OPEN
100% OPEN
100
FactOry dEFaULt
PasswOrd
